3 fázisú okos árammérő ABB AC Terra töltőkhöz – B23 112-100

Leírás

Technical

• Standards: EN 50470-1

• Function: Electricity meter

• Sub-Function: Steel

• Rated Voltage (U_r): 3×220-240 V

• Voltage Range: 3×176…276 V

• Rated Current (I_n): 5 A, Maximum 65 A

• Current Rating: 5 A

• Rated Frequency (f): 50 / 60 Hz

• Power Consumption (@P_cons): 0.721 W

• Communication Interface: Modbus RS485

• Accuracy: Active Energy Class B MID (±1%)

• Measuring Instrument Conformity: Measurement Instrument Directive (MID)

• Meter Tariff Rating: One-Tariff

• Pulse Output Rate: 1-999999

• Number of Poles: 4

• Number of Phases: Three-phase

• Number of Counter Positions: 7

• Number of Digital In/Outputs: 1 DO

• ABB Type Designation: B23 112-100

• Meter Type: Direct connected

• Mounting Type: DIN rail

• Pulse Output Type: Electrical

• Type of Indicator: Digital

• Enclosure Material: Polycarbonate in transparent front glass. Glass reinforced polycarbonate in bottom case and upper case. Polycarbonate in terminal cover.

• I/O Option: 1 digital output

• Communication: Modbus RTU

• Connecting Capacity Main Circuit: 1 … 25 mm²

Environmental

• Ambient Air Temperature: Operation -40 … 70 °C

• Degree of Protection: IP20

• RoHS Status: Following EU Directive 2002/95/EC August 18, 2005 and amendment

• Environmental Information: 2CMC485003D0001
